กล้องวงจรปิด โดม IP 5MP DH-IPC-HDBW5541E-ZE

Image Sensor

1/2.7" CMOS

Max. Resolution

2960 (H) × 1668 (V)

RAM/ROM

1GB /4 GB

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.0009 lux@F1.5(Color, 30 IRE)
0.0005 lux@F1.5(B/W, 30 IRE)
0 lux (Illuminator on

Scanning System

Progressive

IR Distance

40 m (131.23 ft) (IR)

IR On/Off Control

Auto;Zoomprio; Manual

Angle Adjustment

Pan: 0°–355°
Tilt: 0°–65°
Rotation: 0°–355°

Max. Aperture

F1.5

Field of View

H: 114°–32°; V: 58°–17°; D: 138°–36°

Close Focus Distance

0.8 m (2.62 ft)

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Main stream: 2960 × 1668@(1–25/30 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
Fourth stream: 720p@(1–25/30 fps)
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be subjected
to the total encoding capacity.

Resolution

5M (2960 × 1668); 5M (2880 × 1620); 4M (2688 × 1520);3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 ×1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240

Video Bit Rate

H.264: 32 kbps–16384 kbps; H.265: 12 kbps–11776 kbps

Day/Night

Auto(ICR)/Color/B/W

Power Supply

12 VDC/24 VAC/PoE (802.3af)/ePoE

Power Consumption

Basic: 3.9 W (12 VDC); 4.6 W (24 VAC); 5.6 W (PoE) Max. (H.265+ WDR+ Intelligence on+IR on): 10 W (12VDC); 11.7 W (24 VAC); 12.1 W (PoE)

Product Dimensions

Φ159.1 mm × 118.1 mm (6.26" × Φ4.65"

Net Weight

0.91 kg (2.01 lb)

Gross Weight
